Carbide Strips for Paper Cutting
Paper cutting machine blades play a vital role in paper production. They can be used in the automatic paper cutter, CNC paper cutter, and series paper cutter. Tungsten carbide strips for paper cutting are ideal for manufacturing paper cutting blades in the printing and packaging industries. KoneCarbide offers top and consistent quality carbide strips for paper cutting.
Features:
- Micro-grain carbide;
- Varied grades;
- Excellent cutting efficiency;
- Longer service life;
- Both ground and unground carbide strips are available;
- High and consistent quality;
- Customization service is available.
Request for quotation for detailed information (MOQ, price, delivery, etc) or request our carbide blanks catalog. Our sales team and engineers will work together to provide you with the most cost-efficient solution.
Share:
Share on facebook
Share on twitter
Share on linkedin
| Length (mm) | Width (mm) | Thickness (mm) | Tolerance |
|---|---|---|---|
| 370 | 25 | 2.5 | L(+3.0~+5.0) W(+0.8~+1.5) T(+0.15~+0.35) |
| 390 | 25 | 2.5 | |
| 405 | 25 | 2.5 | |
| 415 | 25 | 2.5 | |
| 424 | 25 | 2.5 | |
| 460 | 25 | 2.5 | |
| 480 | 25 | 2.5 | |
| 540 | 25 | 2.5 | |
| 560 | 25 | 2.5 | |
| 580 | 25 | 2.5 |
| Grade | Grain Size | Density (g/cm³) | Hardness (HRa) | T.R.S (N/m㎡) |
|---|---|---|---|---|
| TF25 | Sub-Micron | 14.52 | 91.8 | 2950 |
| GS25 | Sub-Micron | 14.4 | 91.7 | 3200 |
| GM21 | Medium | 14.9 | 90.5 | 2300 |
| GM23 | Medium | 14.7 | 89.5 | 2520 |
| GC30 | Coarse | 13.9-14.1 | 85.7 | 2800 |
